19.5" x 6" - Hub Pilot - 225mm Bolt Circle
76329x
76329x
76329x-dual
76329x-ford-1
76329x-ford-2
76329x-ford-3
76329x-ford-4

Ensure your wheels match the quality and passion of your dually truck. Forged aluminum wheels specifically for the RAM 4500/5500 and Ford F450/550.

warranty
Hub-Bore
Where To Buy
Specifications Measurement
Product Part Number 76329x
Wheel Size (in) 19.5" x 6"
Mounting System Hub Pilot
Bolt Holes 10
Bolt Circle 225mm
Bolt Hole Diameter 15mm
Hub Bore 170.2mm
Approx. Weight (lbs) 26 lbs
Outset (in) 5.35"
Inset (in) 4.82"
Max Load (lbs) 4000 lbs
Max Cold Infl. (psi) 130 psi
Valve Stem TR553C
Part Number Finish
763291 Mirror Polish Outside Only
763291DB Mirror Polish Outside Only with Dura-Bright
763292 Mirror Polish Inside Only
763292DB Mirror Polish Inside Only with Dura-Bright
763297 High Polish
Accessories and Mounting Hardware Part Number
Front Hub Cover
(Includes Nut Covers Where Applicable)		 001004, 001006
Rear Hub Cover
(Includes Nut Covers Where Applicable)		 001005, 001007
Nut Cover Only
(Not Intended to Secure Hub Covers)		 N/A
Alcoa® Mounting Hardware Kits See OEM

Related Documents

Where To Buy Email Results

0 0 and 7 finish options are determined by inset or outset mounting positions and may not be finished on both sides. See chart for position and available finish options.
1Hub cover system kits with part numbers 076185 (front), 077185 (rear), 082122 (front), and 082133 (rear) contain screw-on Hug-A-Lug® nut covers and require a minimum of four (4) threads of the stud to extend above the tightened cap nut for use. Six (6) threads are recommended.
2082012 (30mm kit Front and Rear).
3OEM exclusive. Purchase through Peterbilt dealer only.
4OEM exclusive. Purchase through Kenworth dealer only.
5OEM exclusive. Purchase through Volvo dealer only.
†See our Warranty page for more information

See Wheel Accessory Products Catalog for part number specific fitment information. Always perform a fitment check to ensure accessories are secure before operating vehicle.
